Cerelog Brain Computer Interface EEG Base Circuit Board

What's Included

• 1x Cerelog EEG Circuit Board
• 1x Protective case 3D print file (STL format)

Technical Specifications

Input Channels 8 differential channels + 1 bias probe

ADC Resolution 24-bit

Sample Rate Up to 16,000 SPS per channel

Power Supply 5V USB-C power

Electrode Compatibility Active and passive electrodes

Additional Features Advanced noise suppression, DC bias correction, high-precision timing

Research Applications

The Cerelog EEG Circuit Board is designed for research applications including:

• EEG (Electroencephalography) studies
• EMG (Electromyography) measurements
• ECG (Electrocardiography) monitoring
• Brain-Computer Interface (BCI) development

Quantity

Research-grade signal quality

Compatible with active and passive electrodes

Technical support included

Need help? Contact our research support team at support@cerelog.com

Compatible Accessories

EEG Skull Cap

Third-Party Product

Compatible skull cap for optimal electrode placement following the international 10-20 system.

• Precise 10-20 system positioning

• Sintered Ag/AgCl metal Ear Clip Electrodes

• Adjustable sizing for reliable fit

Purchase Skull Cap

Note: This is a third-party product selected for compatibility with the Cerelog EEG Circuit Board. While we've verified basic compatibility, we recommend reviewing the specifications for your specific needs.

Important Notice

This product is intended for research, engineering, and educational purposes only. It is not a medical device and has not been evaluated by the FDA. The product is not UL or FCC certified.

This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSES ONLY and is not considered by Cerelog Inc. to be a finished end-product fit for general consumer use.

We expressly disclaim any liability whatsoever for any direct, indirect, consequential, incidental or special damages, including, without limitation, lost revenues, lost profits, losses resulting from business interruption or loss of data.
